AN40 is the Hot Wire Type Wind Speed Airflow Meter. By adopting new sensor technology with major improvements in ATC (Automatic Temperature Compensation), AN40 can measure accurately in-duct Air Velocity measurements with changing air temperatures. It comes with a telescoping rod with scale that extends up to 7ft (2.1m), which ensures that measurements are made in the center of the duct even if it is out of reach. Reads Air Velocity and Temperature on dual display and adjustable parameters for Atmospheric Pressure and GAIN provide confident readings. Complete with telescoping rod with cable, 100V-240V AC universal adaptor with 4 plugs, six AA batteries, and hard carrying case.
Specifications:
| Specifications | Range |
| Air Velocity | 0.00~9.99, 10.0~20.0m/s |
| 0.0~75.0km/h | |
| 0~4000ft/min | |
| 0.0~45.0MPH | |
| 0.0~40.0knots | |
| Air Flow | 0.0~1298.0 CMM |
| 0~45922 CFM | |
| Temp. | 0.0~60.0°C (0.0~140.0°F) |
| Max. Resolution | 0.01m/s, 0.1km/h (MPH, knots) |
| 1ft/min, 0.1CMM, 1CFM, 0.1°C /°F | |
| Accuracy | ±(3% rdg+ 0.2) m/s, ±1.8°F/1°C |
| Dimensions/ Weight | 6.3x3.2x1.7" (160x81x43mm)/ 8.6oz (244g) |
Features:
